Vanguard model 38 40hp performance parts kit

This is a performance parts kit for you if you are starting with a model 38vanguard (21-23 hp). This kit is for 7000 rpm max. It includes almost all the parts required for your full build. These kits were formulated using our flow bench results on the oem heads and intake and our engine building software. We do the exact same procedure when building our own engines. You have to do all the work yourself. This is theoretical power, this has to be built by an experienced engine builder. This kit is for stock unported heads and using a briggs double barrel intake and carb. These kits can take a couple months to ship. Here is what the kit includes:

Model 38 vanguard stock heads stock intake 315 cam 7000 rpm 40

315 cam

lash caps

pushrod kit

rods 4.262

spring kit steel retainers

valve set

billet 2.97 pistons

flywheel

exhaust kit

air filter adapter

air filter

gasket kit

sump stud kit

cylinder head stud kit

More info about this kit: Some info may be repeated. This kit is based on what stock 21-23hp heads flow from the factory without porting (80cfm) . Then the intake is taken into consideration. This kit uses the oem 21-23hp double barrel intake and carburetor , it does not outflow what stock heads can flow (80 cfm) so it DOES NOT handicap the heads. The rest of the kit has been sized and matched correctly for the proper operating rpms and power level achieved. This is simply a grouping of parts needed for a complete build. There is no savings or premium from buying all these parts separately. Basically we set this kit up the way we would build an engine ourselves at this power level using this platform. If you want the computer software generated build sheet after purchasing it let us know via email. We will send it.
